Precision Calibration Bath / Low Temperature Calibration Bath
Product Features
It adopts double-chamber side-stirring working mode, and the uniformity of the temperature field is good.
Intelligent PID control, with good temperature field stability and uniformity.
Color display instrument with high resolution, resolution 0.001 degrees Celsius.
The imported compressor has stable and reliable performance, and the optimized refrigeration system cools down faster.
RS-232/RS-485 communication interface is optional, which can realize calculation control.
The humanized design is suitable and convenient to operate.
Request a Quote
Or Call +86-0538-5089056
Description
Download
Product Description
DTS-G Precision Calibration Bath / Low temperature calibration bath is the ideal temperature constant temperature equipment for verifying and calibrating various low temperature thermocouples, industrial thermal resistance, pressure thermometers, bimetal thermometers, glass liquid thermometers and other temperature sensors.
The tank of constant temperature tank body adopts the structure of lateral stirring in the design. The technical indicators of the temperature field in the working area meet the technical requirements of the temperature uniformity and temperature fluctuation of the constant temperature tank. At the same time, this series of liquid thermostatic oil tanks have simple operation and convenient use. Etc.(Special index products can be customized according to requirements)
Technical Parameters
| Product name | Precision thermostatic oil bath | Precision thermostatic water bath | |
|---|---|---|---|
| Model | DTS-300G | DTS-95G | |
| Temperature range | 70-300℃ | RT+10~95℃ | |
| Working medium | Silicone oil | Soft water, antifreeze | |
| Uniformity of temperature field | Level | ≤0.01℃ | ≤0.01℃ |
| Vertical | ≤0.01℃ | ≤0.01℃ | |
| Temperature stability ℃ / 10min | ±0.007℃ | ±0.007℃ | |
| Work area size | φ150×480 | φ150×480 | |
| Volume (L) | 23 | ||
| Power (KW) | 3 | 3 | |
| Dimensions (mm) | 660*540*1120 | ||
| Weight (Kg) | 94 | 94 | |
| Can be customized precision thermostat. | |||
DTS Series precision refrigerated temperature calibration bath is the ideal temperature constant temperature equipment for verifying and calibrating various low temperature thermocouple, industrial thermal resistance, pressure thermometer, bimetal thermometer, glass liquid thermometer and other temperature sensors.
This refrigerated calibration bath adopts the structure of lateral stirring in the design, The technical indicators of the temperature field in the working area meet the technical requirements of the temperature uniformity and temperature fluctuation of the constant temperature tank. At the same time, this series of liquid calibration bath have simple operation and convenient use. Etc.(Special index products can be customized according to requirements)
Technical Parameters
| Product name | Refrigerated Precision Calibration Bath | ||||||
|---|---|---|---|---|---|---|---|
| Model | DTS-01G | DTS-10G | DTS-30G | DTS-40G | DTS-60G | DTS-80G | |
| Temperature range | 0~100℃ | -10~100℃ | -30~100℃ | -40~100℃ | -60~100℃ | -80~100℃ | |
| Working medium | Antifreeze | anhydrous ethanol | |||||
| Uniformity of horizontal temperature field | ≤0.01℃ | ≤0.010℃ | ≤0.010℃ | ||||
| Uniformity of vertical temperature field | ≤0.01℃ | ≤0.010℃ | ≤0.010℃ | ||||
| Temperature fluctuation :℃/10 min | ±0.01℃ | ±0.010℃ | ±0.010℃ | ||||
| Work area dimensions | φ130×480 | ||||||
| Volume :(L) | 18.5 | ||||||
| Maximum power :(KW) | 2 | 2.8 | 3 | 3 | |||
| Dimensions :(mm) | 660(L)×540(W)×1120(H) | 700*590*1120 | |||||
| Quality :(Kg) | 95 | 115 | 155 | ||||
